Product Info

Specifications: - Power adapter model: UES48-150320SPA1. - Power input: 100-240V~ 50/60Hz 1.1A. - Internal power supply: DC 10.8V. - Power adapter output: DC 15.0V 3.2A. - Type of radiation: X-Ray. - Maximum output electric power: 0.14kw (70kV, 2mA). - Nominal electric power: 0.14kw (70kV, 2mA, 0.1s). - Tube voltage: Tube voltage output is fixed at 70kV, error ±10%. - Tube current: Tube current output is fixed at 2mA, error ±20%. - Focal spot: 0.4 mm. - Target angle: 12.5°. - Dimension: 240 mm × 161 mm × 143mm. - Weight: 2.2 Kg. - Battery specification: 18650×3 10.8V 2500mAh 27Wh R. - Charger: 48W, Full charge in 1 hour. - Exit field size: Φ5.9cm±0.1cm. - Reference Loading conditions: 70kV, 2mA, 1s, loading interval 1s/60s, 59 exposures per hour. - Radiation output stated: The variation coefficient under the function less than 5%.
